OT1250E03CP

Customs Tariff Number

85365080

Brand

ABB Oy, Smart Power, ABB Oy, Smart Power

Minimum Order Quantity

1 piece

Product Net Weight

48 kg

Package Level 1 Units

1 piece

Package Level 1 Depth / Length

600 mm

Package Level 1 Height

550 mm

Package Level 1 Width

500 mm

Package Level 1 Gross Weight

51 kg

Mounting Type

Base mounting

Declaration of Conformity - CE

1SCC303016D0201

RoHS Information

1SCC301149D0202

ETIM 7

EC000216 - Switch disconnector

ETIM 8

EC000216 - Switch disconnector

WEEE Category

5. Small Equipment (No External Dimension More Than 50 cm)

Degree of Protection

Front IP20

Instructions and Manuals

1SCC301049M0002

Product Net Width

400 mm

Product Net Height

306 mm

Product Net Depth / Length

309 mm

Rated Operational Voltage

1000 V

Rated Insulation Voltage (Ui)

1000 V

Number of Poles

3

Pollution Degree

3

Tightening Torque

acc. IEC 60947-1 50 ... 75 N·m

Power Loss

29 W

Environmental Information

1SCC303050D0201

Package Level 1 EAN

6417019338897

Object Classification Code

Q

ETIM 5

EC000216 - Switch disconnector

ETIM 6

EC000216 - Switch disconnector

E-Number (Finland)

3600147

Country of Origin

Finland (FI)

Handle Color

Black

Handle Type

Handle and shaft included

Position of Line Terminals

Top In - Bottom Out/Bottom In - Top Out

Switches Operating Mechanism

Mechanism at the End of the Switch/03 (Left Side)

Distance Between Phases

Standard

Operating Mode

Front operated

Terminal Width

50 mm

Transition Type

Open
