ESB63-22N-06

Customs Tariff Number

85365080

Brand

ABB Stotz-Kontakt GmbH, ABB Stotz-Kontakt GmbH

Minimum Order Quantity

1 piece

Product Net Weight

0.4 kg

Package Level 1 Units

1 piece

Package Level 1 Depth / Length

57 mm

Package Level 1 Height

69.5 mm

Package Level 1 Width

92 mm

Package Level 1 Gross Weight

0.4 kg

Package Level 2 Units

40 piece

Package Level 2 Depth / Length

395 mm

Package Level 2 Height

210 mm

Package Level 2 Width

280 mm

Package Level 2 Gross Weight

16.7 kg

Declaration of Conformity - CE

1SAD938506-0302

RoHS Information

1SAD938506-0302

RoHS Status

Following EU Directive 2011/65/EU

ETIM 7

EC001653 - Installation contactor for distribution board

Degree of Protection

IP20

Instructions and Manuals

2CDC103043M6801

Product Net Width

54 mm

Product Net Height

85 mm

Product Net Depth / Length

65 mm

Rated Operational Voltage

Main Circuit 220 V DC/Main Circuit 400 V AC

Rated Frequency (f)

Control Circuit 400 Hz/Control Circuit 50 Hz/Control Circuit 60 Hz/Control Circuit DC/Main Circuit 50 Hz/Main Circuit 60 Hz/Main Circuit DC

Rated Insulation Voltage (Ui)

500 V

Number of Poles

4

Pollution Degree

3

Tightening Torque

Control Circuit 0.9 N·m/Main Circuit 2.5 N·m

Wire Stripping Length

Control Circuit 7 mm/Main Circuit 13 mm

Recommended Screw Driver

Control Circuit Pozidriv 1/Main Circuit Pozidriv 2

Standards

IEC/EN 60947-1/IEC/EN 60947-4-1/IEC/EN 61095/UL 60947-1/UL 60947-4-1

Tightening Torque UL/CSA

Control Circuit 8 in·lb/Main Circuit 20 in·lb

Ambient Air Temperature

Operation -25 ... +55 °C/Storage -40 ... +80 °C

ABS Certificate

1SAA920000-0101

CB Certificate

1SAA920005-2001

CQC Certificate

CQC2017010304993562/CQC2017010304993563

EAC Certificate

1SAA920001-2702

Environmental Information

1SAC200065H0009

RINA Certificate

1SAA920000-0801

RMRS Certificate

1SAA920000-0705

Package Level 1 EAN

4013614525513

Package Level 2 EAN

4013614539916

Object Classification Code

Q

ETIM 5

EC001653 - Installation contactor for distribution board

ETIM 6

EC001653 - Installation contactor for distribution board

eClass

V11.0 : 27142308

UNSPSC

39121529

Electrical Durability

AC-1 (NO) 100000 cycle/AC-3 (NO) 240000 cycle/AC-7a (NO) 100000 cycle/AC-7b (NO) 240000 cycle

Mechanical Durability

1000000 cycle

Number of Main Contacts NO

2

Number of Main Contacts NC

2

DNV Certificate

1SAA920000-0306

Horsepower Rating UL/CSA

(220 ... 240 V AC) Single Phase, NC 5 Hp/(220 ... 240 V AC) Single Phase, NO5 Hp/(440 ... 480 V AC) Single Phase, NC 7.5 Hp/(440 ... 480 V AC) Single Phase, NO 7.5 Hp

cULus Certificate

cUL_E191658
